Mini Rotary Tablet Press

Mini Rotary Tablet Press
Mini Rotary Tablet Press
Product Code : 05
Brand Name : RIDDHI
Product Description

Capitalizing on our state-of-art infrastructure and advanced technology, we are considered as the leading manufacturer and exporter of Mini Rotary Tablet Press. These tablet presses are provided with maximum and minimum speed of the turret, which is achieved with the AC variable drive. Our offered tablet presses are developed using superlative quality of raw materials that are procured from the authentic vendors of the market. These Mini Rotary Tablet Press are quality tested with the aid of our diligent analysts and then provided at the customers' place within the stipulated time frame.

Features

  • Robust construction
  • Noise free operation
  • Low maintenance

MINI TABLET PRESS

MINI ROTARY TABLET PRESS (LAB. MODEL) â€Â¢ DESCRIPTION : This rotary tablet press is built as per the GMP directives with total robust construction. At the same time, the necessary care has been taken to have trouble free operation, easy to clean and very low noise level. This state-of-the-art equipment can also be used for small batch production, thanks to its â€ËœBâ€â„¢ tooling specifications like 6 Tons pressure, maximum tablet diameter 16mm etc. which can be utilized for achieving the better output in its range. The maximum/minimum speed of the turret is achieved with the AC variable drive. Also the turret is equipped with key ways in upper guides as a standard feature. This small wonder is totally mobile and can be placed easily on table for laboratory use. As an additional precaution lower punch is equipped with seal(optional). A fixed feed frame ensures easy settings and lowest wastage of material. â€Â¢ SALIENT FEATURES : 1. Easy Movability. 2. Easy to Operate & Clean. 3. Hard Heat Treated Rollers. 4. AC drive with Fixed Pulley. 5. Turret with key ways in Upper guides. 6. Open fixed Feed Frame. 7. Drive from Center Pillar by worm reduction Gear Box. 8. Built as per GMP directive. 9. Fabricated Pressure Roller Carriers. 10. Turret fitted Thrust Bearing. 11. One piece Upper Cam Plate / Track.

â€Â¢TECHNICAL SPECIFICATIONS :

Model              RDMP- 8D        RDMP- 10        RDMP- 8D RDMP- 10B

No . Of Stn.          8                        10                8        10
Tooling         D                        B                 D        B
Max.Output        25,200                25,200        25,200        25,200
Max.Pressure      4 Tons                4 Tons        4 Tons        4 Tons
Pre-Compression                                             1 Ton        1Ton
Max.Tablet Dia.     23 mm                16 mm        23 mm        16 mm
Max . Dpt of Fill   20 mm                17.4 mm        20 mm       17.4 mm
Main Motor          2 H.P..                1.5 H.P.        2 H.P.        1.5 H.P.
