ONLINE VISUAL BOTTLE INSPECTION MACHINE

Product Description

Based on our thorough professional expertise, we have carved a niche in this market for manufacturing and supplying Online Visual Bottle Inspection Machine. These machines are functional for inspecting the quality of bottles designed within the factory. The provided machines are designed in wide options of specifications as to suit the diverse requirements of the clients. Our offered machines are manufactured from superlative stainless steel, which is sourced from the reliable vendors of the market. This Online Visual Bottle Inspection Machine is provided at the patrons' defined place within the limited time.

Features:

• Fast performance
• Longer service life
• High accuracy


ONLINE VISUAL BOTTLE INSPECTION MACHINE

DESCRIPTION

Inspection table is equipment consisting of a three track conveyor with a hood with lighting arrangmenet and visual inspection background of alternate black & white colour. Inspection table have stainless steel structure with moving SS slat chain. Structure made out of SS square pipe & supported on adjustable bolts.

OPERATION

The central conveyor belt bings the bottles from the capping machine conveyor. These bottles are automatically bifurcated on the two adjoining conveyor belts & further on the side tables of operators sitting on either side of the table. The operators in turn pick up the bottles & visually inspect the bottles in the alternate white & black background to check for any particles in the liquid filled, sealed & breakage of bottle. After inspection the bottles are placed in the central track which is transfer for labeling.

TECHNICAL SPECIFICATION

Model                                           RVBI -100                                          RVBI 150

Direction of Movement**               Left to Right                                       Left o Right

Output*                                           Up to 100 containers/minute                 Up to 150 containers/minute.

Number of operator                       Four (2x2, Two Side Seated)              Six (3x2, Two Side Seated)

Power Characteristics**               0.5 HP/ 220 Volts / 50 Hz

Height of Conveyor                       860 mm to 910 mm

Machine Dimension in mm           1880(L) x 700 (W) x 1525 (H)                         2440(L) x 700 (W) x 1525 (H)

Case Dimensions in mm              2150 (L) x 950 (W) x 1750 (H)                        2750 (L) x 950 (W) x 1750 (H)

Net Weight                                    200Kgs.                                                           275Kgs.

Gross Weight                                425Kgs.                             .                             525Kgs.

 Input Specification

                     Round Shape           dia.22mm to dia.100mm**

Container                                      Height 58mm x 240mm**

Size*                                            (Height option for other bottle

                                                       height available)

                     Flat / Square            15 mm to 100 mm (L)

                                                      Respectively 10mm to 50mm (width)

                                                      Respectively Height 58mm to 240mm

                                                      Height option for other bottle

                                                       height available)
