RIDDHI PRESS IV HIGH SPEED DOUBLE ROTARY TABLET PRESS WITH PRE-COMPRESSION

RIDDHI PRESS IV HIGH SPEED DOUBLE ROTARY TABLET PRESS WITH PRE-COMPRESSION
RIDDHI PRESS IV HIGH SPEED DOUBLE ROTARY TABLET PRESS WITH PRE-COMPRESSION
Product Code : RDDD3-IV
Brand Name : RIDDHI
Product Description

RIDDHI PRESS IV HIGH SPEED DOUBLE ROTARY TABLET PRESS WITH PRE-COMPRESSION

AVAILABLE MODELS : 45 STN. D - TOOLING 55 STN. B-TOOLING 61 STN. BB-TOOLING 75 STN. BB-TOOLING

SALIENT FEATURES
  • It is a high speed Rotary tablet press for higher table output, suitable for large batch production.
  • Machine is having a square design with total consideration of GMP standards.
  • All the tablet parameters can be fine tuned during the operation of the machine from front side which are at outside the machine, having SEIKO type dials.
  • The machine is having elegantly designed cabinet top of SS-304.
  • The machine is having round hoppers of SS-304 with Butterfly valve.
  • The machine is having Pre-compression feature.
  • The machine is equipped with A.C. variable frequency drive for the main motor.
  • Machine is also having A.C. variable frequency drive for force feeding motors, which enables operators to synchronize machine’s speed & feed both.
  • The machine is having Electromagnetic clutch arrangements.
  • The machine is having one piece turret of special grade casting. However, three piece turret with SS-304/SS-316 middle plate is also available (optionally). Electro less nickel plating can also be available to the turret (optionally).
  • Lower punch seals are provided at lower punch hole in turret (optionally).
  • The machine is having Helical gear ring to drive the turret.
  • The machine is having hard chrome plated, MS Fabricated upper roll carriers.
  • The machine is having BALL BEARING TYPE upper & lower pressure rolls.
  • The machine is having specially designed pressure Link Assly. Which ensures sufficient & equal pressure to the tablets.
  • The machine is having tablet weight consistency.
  • The machine is having sturdy Aluminium section framed, Polycarbonate guards with SS Hinges & Handle & are also fitted with Gas Filled – Shock absorbers.
  • The lower guard of the machine are of SS-304 material having excellent matt finish.
  • All guards are interlocked for safety.
  • The machine is having auto lubrication system.
  • There is no colour part in tablet manufacturing zone & all other parts are either of SS-304 material or Gunmetal or of hard chrome plated. All Hardware are used of SS-304 quality in tablet manufacturing zone.
  • The machine is having box type Detachable control panel having all electrical controls on the top. Acrylic cover is also provided to protect the controls from the dust.
  • The machine is having center Drive Type Gear Box.
  • The machine is having Hydraulic Power pack for pressure loading and overload release.
  • A Hydraulic Gauge is also provided on lower guard for easy view.
  • The machine is having anti vibrating mounts.
  • The machine is having excellent bottom driven force feeding system for material feeding. However, Gravity type feeding also can be provided. (optionally)
TECHNICAL SPECIFICATIONS :

Models

RDIVD-45

RDIVB-55

RDIVBB-61

RDIVBB-75

Tooling

D

B

BB

BB

No . Of Stations

45

55

61

75

Max . Output(Tab/hr)

325,000

396,000

497,000

540,000

Max . Oper. Pressure(Main)

100 kN

65 kN

65 kN

65 kN

Max . Operating Pressure(Pre-Comp.)

10 kN

10 kN

10 kN

10 kN

Max . Tablet Dia

25 mm

16 mm

11.1

11.1

Max . Depth of Fill

20 mm

17.4 mm

17.4 mm

17.4 mm

Upper Punch Entry

2 to 8 mm

2 to 8 mm

2 to 8 mm

2 to 8 mm

Main Motor

10 HP / 7.5 kW / 3 PHASE / A.C.

Force Feeder Motor

0.25 HP / 8.75 kW / 3 PHASE / A.C.

Total Power Cons.

12 HP / 8.75 kW / 3 PHASE / A.C.

Overall Dimensions

172 x 162 x 192(H)(Cms.) Approx.

Net Weight

3750 Kgs. Approx.
