ROTARY TABLET PRESS MACHINE

ROTARY TABLET PRESS MACHINE
ROTARY TABLET PRESS MACHINE
Send Inquiry
Product Code : RDD3-16
Brand Name : RIDDHI
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Unit/Units, ,
  • Price
  • 650000 INR
Product Specifications
  • Type
  • Tablet Pressing Machine
  • Material
  • POWDER
  • Capacity
  • TABLET SHAPE AND SIZE Kg/day
  • Computerized
  • Yes
  • Control Mode
  • Automatic
  • Voltage
  • 440 VOLTS
  • Power
  • 3 PHASE
  • Weight (kg)
  • 2 TONS
  • Dimension(L*W*H)
  • 4 X 4 X5
  • Color
  • STAINLESS STEEL
  • Warranty
  • ONE YEAR WARRANTY
Product Description

Single Rotary Tabletting Machine STD/GMP Model - 16/20/23 stn.



ROTARY TABLET PRESS MACHINE :




  • Flywheel and Handwheel are provided.
  • Friction plate is provided on cam plate to minimize wear & tear of cam
    track which also facilitates its easy replacement.
  • Re-designed Variable speed pulley.
  • Separate Centre Pillar of C.I. Graded Casting.
  • Turret of C.I. Graded Casting
  • Very rigid Gun-metal Feed frame with sufficient height
    to avoid spill over of powder.
  • All Columns and Nuts are electroplated.
  • Central Oil Lubrication system with hand pump.
  • Pressure gauge provided to check compression load.
  • Excellent finish, Accessibility for ease of cleaning,
    operation and Maintenance..
  • Oil groove on top face of turret for collection of excess oil.
  • Overload pressure release mechanism to give
    protection against excess pressure.
  • Upper and Lower Pressure Rolls are made out of alloy steel for
    maximum wear resistance and long life.
  • Worm is made up of Phosphor Bronze.
  • RDD3-23 station machine can compress D.S.
    tablet upto 16mm (5/8”) in length.
  • Turret with Key slots essential for shaped tooling.
  • Maximum Turret RPM for STD Machine is 30.

ADDITIONAL SALIENT FEATURES FOR GMP MACHINE :

  • Machine is totally enclosed, i.e. Top half of the machine Compression zone) with S. S hood &
    acrylic covers and Lower half of the machine complete with Mat finished S.S. covers.
  • This reduces the noise level and to & fro flow of dust between compression
    zone and compression room.
  • Anti vibration mounting pads are provided, hence no foundation is required.
  • Large paint free compression zone with plenty of space for ease of cleaning &
    Accessibility of components.
  • Electronic Counter showing total output is provided on the control panel.
  • Operating system same as standard machine and it is easy to operate and maintain
    the machine.
  • Most of the components are common with the standard machine which reduces inventory
    of spares.
  • Higher Turret speed upto 42 RPM gives higher output than standard machine.
  • Maximum Turret RPM for GMP Machine is 42.



Technical Specification :



Model RDD3-16 RDD3-20 RDD3-23
Tooling D D B/D Combined
No . Of Stations 16 20 23
Max.Output (Tab/hr) 40,320 50,400 57,960
Max . Pressure 10 Tons 10 Tons 10 Tons
Max . Tablet Dia. 23 mm 23 mm 16 mm
Max . Depth of Fill 19 mm 19 mm 19 mm
Main Motor 2 H.P./ 960 RPM / 3 Ph., A.C. Supply
Overall Dimensions 137 x 137 x 212(Cms.) Approx.
Net Weight 1070 Kgs. Approx...
Trade Information
  • FOB Port
  • FOB MUMAI JNPT PORT
  • Supply Ability
  • 4 MACHINE Per Month
  • Delivery Time
  • 6-8 Week
  • Packaging Details
  • SEA WORHTY PACKING
  • Main Export Market(s)
  • Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Asia
  • Main Domestic Market
  • All India
