SINGLE ROTARY TABLET PRESS MACHINE

SINGLE ROTARY TABLET PRESS MACHINE
SINGLE ROTARY TABLET PRESS MACHINE
Product Code : RDD3-16
Brand Name : RIDDHI
Product Description

Single Rotary Tabletting Machine STD/GMP Model - 16/20/23 stn.



SALIENT FEATURES FOR STD & GMP MACHINE :




  • Flywheel and Handwheel are provided.
  • Friction plate is provided on cam plate to minimize wear & tear of cam
    track which also facilitates its easy replacement.
  • Re-designed Variable speed pulley.
  • Separate Centre Pillar of C.I. Graded Casting.
  • Turret of C.I. Graded Casting
  • Very rigid Gun-metal Feed frame with sufficient height
    to avoid spill over of powder.
  • All Columns and Nuts are electroplated.
  • Central Oil Lubrication system with hand pump.
  • Pressure gauge provided to check compression load.
  • Excellent finish, Accessibility for ease of cleaning,
    operation and Maintenance..
  • Oil groove on top face of turret for collection of excess oil.
  • Overload pressure release mechanism to give
    protection against excess pressure.
  • Upper and Lower Pressure Rolls are made out of alloy steel for
    maximum wear resistance and long life.
  • Worm is made up of Phosphor Bronze.
  • RDD3-23 station machine can compress D.S.
    tablet upto 16mm (5/8”) in length.
  • Turret with Key slots essential for shaped tooling.
  • Maximum Turret RPM for STD Machine is 30.

ADDITIONAL SALIENT FEATURES FOR GMP MACHINE :

  • Machine is totally enclosed, i.e. Top half of the machine Compression zone) with S. S hood &
    acrylic covers and Lower half of the machine complete with Mat finished S.S. covers.
  • This reduces the noise level and to & fro flow of dust between compression
    zone and compression room.
  • Anti vibration mounting pads are provided, hence no foundation is required.
  • Large paint free compression zone with plenty of space for ease of cleaning &
    Accessibility of components.
  • Electronic Counter showing total output is provided on the control panel.
  • Operating system same as standard machine and it is easy to operate and maintain
    the machine.
  • Most of the components are common with the standard machine which reduces inventory
    of spares.
  • Higher Turret speed upto 42 RPM gives higher output than standard machine.
  • Maximum Turret RPM for GMP Machine is 42.



Technical Specification :



ModelRDD3-16RDD3-20RDD3-23
ToolingDDB/D Combined
No . Of Stations162023
Max.Output (Tab/hr)40,32050,40057,960
Max . Pressure10 Tons10 Tons10 Tons
Max . Tablet Dia.23 mm23 mm16 mm
Max . Depth of Fill19 mm19 mm19 mm
Main Motor2 H.P./ 960 RPM / 3 Ph., A.C. Supply
Overall Dimensions137 x 137 x 212(Cms.) Approx.
Net Weight1070 Kgs. Approx...
