Augur Type Dry Syrup Powder Filling Machine

Augur Type Dry Syrup Powder Filling Machine
Augur Type Dry Syrup Powder Filling Machine
Send Inquiry
Product Code : 24
Product Description
The Automatic Single Head Linear Augur type Dry Syrup Powder Filling Machine Model RDPF-60, is suitable for Filling Dry Syrup Powder in various type and shape of bottles with maximum speed of 40 Bottles per minute depending on Fill Volume, type of Powder and Bottle Size. Machine with proven Augur type Powder Filling System for filling higher grammage of Powder in Single Dose. All Parts coming in contact with powder are made from Ss316, Nylon and HDPE material.

  • No Bottle - No Fill System
  • All contact parts made of Ss316 and Nylon/HDPE material with easy removal system for Cleaning
  • Machine construction in SS304 material
  • A. C. Variable Frequency Drive Speed Control
  • Filling Accuracy of +/- 1% to 3% depending on powder at controlled humidity below 30% Rh
  • Low Air - Machine Stop System
  • Heavy Duty Mounting system for Powder Wheel for Trouble Free long term operations
Technical Specifications

Bottle Diameter

25mm to 85mm*

Product Height

100mm* Maximum>

Fill Range

5gms. To 60gms. In Single Dose System


+/- 2 to 3% Depending upon the Powder, under the controlled level of Humidity


Below 30% Rh required on machine to be arrange by customer


415VAC 3Phase and 220 VAC Single Phase Power Supply (50 Hz) with A.C. Drive


2.0 H.P.

Conveyor Height

815-940 mm

Overall Dimensions

3500 mm (L) x 1200 mm (W) x 1900 mm


Max. 40 Bottles per minute
