DOUBLE LAYER TABLET PRESS MACHINE
Product Details:
- Type DOUBLE LAYER TABLET PRESS MACHINE
- Material Stainless Steel
- Control Mode Semi-Automatic
- Voltage 440 Volt (v)
- Color Silver
- Warranty 1 Year
- Click to view more
X
Price And Quantity
Product Specifications
- 1 Year
- Semi-Automatic
- Stainless Steel
- Silver
- DOUBLE LAYER TABLET PRESS MACHINE
- 440 Volt (v)
Trade Information
- Western Europe, Central America, Asia, South America, Eastern Europe, Middle East, North America, Australia, Africa
- All India
Product Description
ABLET COMPRESSION MACHINE
We are one of the pioneer Pharmaceutical Machinery Manufacturers from India, We manufacture a variety of Tablet Press from small to volumes to large volumes. We have different models in Tablet Compression Machine, this is Double Rotary Tablet Press it comes in four models RDB4-27D, RDB4-27, RDB4-35, RDB4-45 from 27 station D tooling, 27 station B tooling to 45 station BB tooling. We also manufacture Single Rotary Tablet Press which comes in 3 models, 16,20,23 station. This Tablet Compression Machine is having 10 ton pressure with Upper Punch Penetration and optional Disk type Clutch start system.
Tablet Compression Machine - Double Rotary Tablet Press - RMB4
Application :
- Square GMP Model.
- C.I. Body and C.I. Middle plate
- Paint free tablet manufacturing zone.
- Turret of S.G. Iron Special Grade Casting
- Separate centre pillar of C.I. graded casting.
- Disc type friction clutch start system.
- Upper Punch Penetration system
- Electronic Digital Tablet cum RPM Counter.
- Inter lock switches to all Guards.
- Double Sided lifting cams.
- Lower Guard of Stainless Steel & Upper Guards of Acrylic Material.
- Aluminum Turret Guards. 13. Effective Dust Extraction Nozzles.
- Imported needle roller bearing provided at the bottom of turret.
- Re-designed Variable Speed Pulley, One shot Lubrication System and Anti Vibrating Mounts are provided.
- Very rigid Gun metal Feed frame (both identical) with sufficient height to avoid spill over of powder
- Turret with key slots, essential for shaped tooling provided on 27, 33, 35 & 37 station machine (optional on 41 & 45 station machine.)
- Separate, front and rear take off chutes to avoid any blockage or double compression resulting in accident.
- Oil groove on top face of turret for collection of excess oil.
Special Additional Features
Technical Specification
- S.S. Turret Die / Middle Plate.
- A.C. Frequency Drive for Main Motor.
- Square GMP Model with S.S. Lower Half Enclosures.
- Safety Switches at Acrylic Guards.
- Automatic Centralised Lubrication System.
- Upper Punch Penetration.
Technical Specification
| Models | RDB4-27D | RDB4-27 | RDB4-35 | RDB4-45 |
| No . Of Stations | 27 | 27 | 35 | 45 |
| Type of Tooling | D | B | B | BB |
| Output Tab./Min. | 900-2268 | 900-2268 | 1167-2940 | 1500-3781 |
| Max.Op. Pressure | 100 kN | 65 kN | 65 kN | 65 kN |
| Max. Tab. Dia. | 25 mm | 16 mm | 16 mm | 11.1 mm |
| Max. Dpt. of Fill | 20 mm | 17.5 mm | 17.5 mm | 17.5 mm |
| Upper Punch Pen | 1.5-8 mm | 1.5-8 mm | 1.5-8 mm | 1.5-8 mm |
| Max. Turret RPM | 40 RPM | 40 RPM | 40 RPM | 40 RPM |
| Main Motor | 4 / 5 HP, 1440 RPM, 3 Ph. A.C. Supply | |||
| Overall Dmns. | 1040 x 1000 x 1790H (mm) Approx. | |||
| Net Weight | 1150 Kgs. Approx. | |||
