MONOBLOC

MONOBLOC

Product Details:

X

Product Description

Owing to our wide expertise in this domain, we are benevolently manufacturing and exporting Liquid Filling Machines. These machines are available for the clients at extremely low costs, as compared to other similar availabilities in the market. Our offered machines are instrumental in filling containers of any capacity with liquid. These machines are  designed with superlative quality raw materials, which are obtained from the reliable sources of the market. Our Liquid Filling Machines are tested for quality with the help of our analysts before the final dispatch.

Features:

  • Noise free operation
  • Rugged construction
  • Low maintenance

ROTARY VOLUMETRIC BOTTLE LIQUID FILLING AND R.O.P.P MACHINE MONOBLOC – 8X8


DESCRIPTION:

Automatic Rotary Piston Filling Cum Sealing Machine is versatile, self-supported on stainless steel leg with height adjustable adjustment system. The machine is precision built on sturdy welded MS frame completely enclose in stainless steel sheet and doors are providing to facilitate the servicing of machine, work on volumetric principle with rotary motion. The unit is made compact, versatile and enclosed in stainless steel elegantly matt finish body. No container No filling & No Sealing system arrangement is standard features of the machine.


The main drive of the machine, conveyor drive & cap-feeding bowl consist of A/c Motor with synchronized variable A/c Frequency Drive.


OPERATION:

Containers moving on SS Slat conveyor, feed below the filling nozzles through feed worm & in-let star wheel, Filling station consist of volumetric filling head and a central rotating liquid reservoir tank. This reservoir tank fed continuously with the liquid by external source. In-feed liquid controlled automatically by sensing the liquid level in the reservoir tank with the help of float switch to actuate pneumatically operated solenoid valve. Fill volume adjustment can be done by a screw, which changes the volume of all the syringes simultaneously. Fine adjustment of individual syringe is possible with the help of mechanism provided on top of the individual syringe.


After filling star wheel bringing the containe below the sealing head in the subsequent indexing part, mean while the bottle pickup a cap from the delivery chute of cap filling bowl, where the body and the neck of the container are positioned below the rotating head, where the sealing head is performing perfect operation of threading & sealing.
