Pass Through Oven LAF

Product Description

Pass Through Oven

The Riddhi pass-through oven saves time when loading and reduces the danger of contamination, especially when directly transporting the chamber load between the grey room and the clean room.

The Riddhi  heating oven with fully insulated stainless steel door on both sides saves time during loading and

reduces the risk of contamination, specially when handling sensitive load between grey and clean rooms.

Model                                               :     12-24-48-96-192 TRAYS GMP MODEL

OVERALL SIZE Dimension                          :       2200 (L) X 1200 (W) X 2150 (H)

TEMPERATURE                                            :       Up to 150 C

INSIDE SHEETING                                    :      16 Guaqge Thick S. S. 304 Sheet Full welded.

OUTSIDE SHEETING                                :      14 Guage Thick S. S. 304

DOORS                                                         :       2 Doors Double Walled.

INSULATION                                              :     75 mm Thick Fibre Glass wool in all

.                                                                     Sides, top, bottom & door.

ELECTRICAL HEATER                             :       12 KW ( Tubler
