Product Description

SINGLE ROTARY TABLET PRESS

SALIENT FEATURES FOR STD & GMP MACHINE :

1.     Flywheel and Handwheel are provided.

2.     Friction plate is provided on cam plate to minimize wear & tear of cam track which also facilitates its easy replacement.

3.     Re-designed Variable speed pulley.

4.     Separate Centre Pillar of C.I. Graded Casting.

5.     Turret of C.I. Graded Casting.

6.     Very rigid Gun-metal Feed frame with sufficient height to avoid spill over of powder.

7.     All Columns and Nuts are electroplated.

8.     Central Oil Lubrication system with hand pump.

9.     Pressure gauge provided to check compression load.

10. Excellent finish, Accessibility for ease of cleaning, operation and

     Maintenance.

11.Oil groove on top face of turret for collection of excess oil.

12.Overload pressure release mechanism to give protection against excess

     pressure.

13.Upper and Lower Pressure Rolls are made out of alloy steel for maximum

     wear resistance and long life.

14. Worm is made up of Phosphor Bronze.

15. RDD3-23 station machine can compress D.S. tablet upto 16mm (5/8) in length.

16.Turret with Key slots essential for shaped tooling.

17.Maximum Turret RPM for STD Machine is 30.

ADDITIONAL SALIENT FEATURES FOR GMP MACHINE :

1.     Machine is totally enclosed, i.e. Top half of the machine Compression zone) with S. S hood & acrylic covers and Lower half of the machine complete with Mat finished S.S. covers.

2.     This reduces the noise level and to & fro flow of dust between compression zone and compression room.

3.     Anti vibration mounting pads are provided, hence no foundation is required.

4.     Large paint free compression zone with plenty of space for ease of cleaning & Accessibility of components.

5.     Electronic Counter showing total output is provided on the control panel.

6.     Operating system same as standard machine and it is easy to operate and maintain the machine.

7.     Most of the components are common with the standard machine which reduces inventory of spares.

8.     Higher Turret speed upto 42 RPM gives higher output than standard machine.

9.     Maximum Turret RPM for GMP Machine is 42.

TECHNICAL SPECIFICATIONS FOR 12 STATION SINGLE ROTARY SLUGGING &COMPRESSION TABLET MACHINE (FOR VETERINARY & BOLUS PURPOSE)

Models                                              RD3SH-12

Tooling                                              Special

No. of Stations                                   12

Maximum Output (Tablet /hour)      15,600

Maximum Operating Pressure          12 Tons

Maximum Tablet Diameter                40 mm

Maximum Depth of Fill                     30 mm

Main Electric Motor                           3 HP/960 RPM/3 Ph. A.C. Supply

Overall Dimensions                           137 x 137 x 212(Cms.) Approx.

Net Weight                                        1070 Kgs. Approx.

TECHNICAL SPECIFICATIONS FOR SINGLE ROTARY TABLE PRESS GMP MODEL MACHINE

Model                            RDD3-16           RDD3-20           RDD3-23

Tooling                           D                        D                        B/D Combined

No . Of Stations              16                      20                      23

Max . Output (Tab/hr)   40,320               50,400               57,960

Max . Pressure               10 Tons              10 Tons              10 Tons

Max . Tablet Dia.            23 mm               23 mm               16 mm

Max . Depth of Fill         19 mm               19 mm               19 mm

Main Motor                      2 H.P./ 960 RPM / 3 Ph., A.C. Supply

Overall Dimensions               137 x 137 x 212(Cms.) Approx.

Net Weight                                  1070 Kgs. Approx.
