STRIP PACKING MACHINE

Product Description

By utilizing advanced technology, we are manufacturing and supplying highly functional Strip Packaging Machine. Our offered machine can perform automatic feeding, sealing, slitting and cutting automatically. These equipments are engineered using stainless steel, in accordance with the GMP standards. The provided machines are available for the customers in different specifications and sizes along with customized models. Our Strip Packaging Machine is widely used in pharmaceutical industries for packaging purpose.

Features:

• Easy to operate
• High operational fluency
• Easy to clean


FULLY AUTOMATIC STRIP PACKING MACHINE

PRODUCT INFORMATION

Automatic Strip Packing Machine is built on advanced technology to fulfill the requirement in Pharmaceutical Packing Industry. Strip Packing Machine gives high speed and unintemrpted performance at low maintenance cost. They are ideal for high speed sealing of coated or uncoated tablets, capsules or lozenges of any shape or size in Aluminium foils, Polythene, cellophane or any other heat sealing material.

FEATURES

• Automatic Feeding, Sealing, Slitting and Cutting are done simultaneously. Therefore, its efficiency is high, meaning production cost is decreased due to reduction of labour cost.

• The exterior of the machine is made out of Stainless Steel, which makes it easy to be cleaned and meet G.M.P.

• It is easy to operate and anyone can learn the operation instantly.

• The change parts can easily replaced.

FLOW CHART

VIBRATOR               :     Which Transports the product through supply tubes to the

Chute. The Device grips the various pieces and centers them for their entry into the Sealing Roller.\

CHUTE                     :     The Device grips the various pieces and centers them for their

                                       entry in to the sealing Roller.

SEALING ROLLER: The Temperature of Sealing Roller can be steadily maintained because precise temperature control device is adopted.

SLITING                    :     The column number and location of the slitting can adjusted

                                       easily.

DRAW BRUSHES   :     Tense the strip makes sure the Sealing and Cutting is perfect.

CUTTER                  :     The row number of cutting can be adjusted as per your

TECHNICAL SPECIFICATION

DRIVE MOTOR       :     0.5 HP 3 Phase 415 Volts 50Hz

NET WEIGHT          :     450.000 Kgs.

GROSS WEIGHT    :     750.000 Kgs.

DIMENSION             :     1000(L) X 850 (W)X 1850 (H) MM

MODEL                   4 TRACK           6 TRACK        8 TRACK        10 TRACK      12 TRACK

Foil Width                145mm               210mm            260mm            280mm            310mm

Output /Min.           600-1200            1200-1800       1800-2500       2250-3125       2700-3750

We can also supply special purpose machinery to Pack Refills, Mosquito Mats, Candies, Granules, Powders, solid and semi solid up to 20gms.
