V Blender

Product Description

V BLENDER GMP MODEL

INTRODUCTION :

The rotating shell V-Type blenders are used only for dry mixes and have no packing glands(seals) around shafts entering the chamber to cause potential problems.

         SALIENT FEATURES:

1. Minimal Attrition when blending granules.
2. Large-Capacity equipment available.
3. Easy to load and unload.
4. Easy to clean.
5. Minimal maintenance.

         BRIEF DESCRIPTION :

1.       Main Shell :

Two cylindrical shells of suitable diameter and length are welded at an angle of 65 to 75 depending upon its capacity. Main shells are made out of S.S. 316L quality sheet metal with mirror polished inside and matt polished outside.

2.       Support :

The Blender will be supported on structural supports both sides with "A shaped S.S. 304 quality tubular pipe. The blender is mounted on pillow block bearings fitted on supports. Also the drive unit is mounted on the side of support.

3.       Openings :

Top side of the blender will be provided with hinge type lids of suitable diameter with quick opening type for loading the material. Bottom side blender will be provided with suitable butterfly valve for discharge the material.

1.       Drive :

A 7.5 H.P. motor with worm reduction gear box is provided with fixed speed. A.C. frequency drive can be provided at an extra cost. Complete assembly is covered with a Stainless Steel AISI 304 quality enclosure.

2.       Safety Guard :

A Stainless Steel AISI 304 quality tubular guard with limit switch will be provided on the operator side and backside of blender is provided will be fixed.

3.       Control Panel :

A semi automatic type control panel with digital batch timer with ON, OFF & INCH push buttons will be provided on front side of the machine.
