Rotary Volumetric Bottle Liquid Filling And R.O.P.P Machine (MONOBLOC)

Rotary Volumetric Bottle Liquid Filling And R.O.P.P Machine (MONOBLOC)
Rotary Volumetric Bottle Liquid Filling And R.O.P.P Machine (MONOBLOC)
Send Inquiry
Product Code : RDMB
Brand Name : RIDDHI
Price And Quantity
  • Minimum Order Quantity
  • 3
  • Unit of Measure
  • Unit/Units
  • Price
  • 1500000 INR
Product Specifications
  • Product Type
  • bottle filling machine
  • Material
  • stainless steel
  • Application
  • Medical, Food, Chemical, Beverage
  • Packaging Material
  • Wood
  • Computerized
  • Yes
  • Automatic Grade
  • Automatic
  • Control System
  • Human Machine Interface
  • Drive Type
  • Electric
  • Voltage
  • 440 volts Milliampere (mA)
  • Weight (kg)
  • 1 tons Kilograms (kg)
  • Dimension(L*W*H)
  • 8 x 8 x7 Foot (ft)
  • Capacity
  • 100 bottle per minute Kg/hr
  • Feature
  • Simple Control
  • Color
  • Silver
  • Warranty
  • one year warranty
Product Description
Rotary Volumetric Bottle Liquid Filling And R.O.P.P Machine (MONOBLOC)

Monobloc Rotary Volumetric Bottle Liquid Filling and R.O.P.P Machine offered by us functions on the principle of to pour the liquid in the bottle and seal the cap. Comprising of cap sealing and devices on the same top plate, the machine has capping head ad filling head on the top plate.
The machine delivers the liquid into the bottle while the down position and throughout the up position it sucks liquid from the tank. Filling head includes 8 syringes mounted on the center tank and pistons stroke is set by harmonized system which works up-down position. The syringes have individual valve which is controlled by sensor.

Features

    Drip trays under the conveyor.
    Single Operator for Two Operations.
    Safety Guard for Operation and Protection.
    Electronic Sensor at out feed for Bottle Jamming.
    Less Caps in chute, automatically stop the Machine.
    Separate variator drive to control speed of conveyor.

Technical Specification
Output/Hour*                      2500 to 5400
Number of head/Syringe     6
Direction of Movement**     Left to Right
Fill Size***                           30 ml to 250 ml
Electric Specification**     Main Machine 3 HP / 415Volts / 50 Hz
Oriental Bowl                         0.25 HP / 415Volts / 50 Hz
Conveyor                             0.5 HP / 415 Volts / 50 Hz
Send Enquiry

Trade Information
  • FOB Port
  • jnpt sea port
  • Payment Terms
  • Telegraphic Transfer (T/T), Letter of Credit at Sight (Sight L/C), Letter of Credit (L/C), Cash in Advance (CID)
  • Supply Ability
  • 1 Per Month
  • Delivery Time
  • 8-10 weeks Week
  • Packaging Details
  • sea worthy packing
  • Main Export Market(s)
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
