SINGLE STROKE TABLET PRESS MACHINE

SINGLE STROKE TABLET PRESS MACHINE
Send Inquiry
Product Code : RDSTP
Brand Name : RIDDHI
Price And Quantity
  • Minimum Order Quantity
  • 3 Piece
  • Price
  • 175000 INR
Product Specifications
  • Type
  • Pharmaceutical Packaging Machine
  • Material
  • SS
  • Capacity
  • SINGLE PUNCH ROTARY TABLET PRESS 8, 10, 16, 27, 35, & 45 STATION Kg/hr
  • Computerized
  • No
  • Control Mode
  • Automatic
  • Voltage
  • 440 Volt (v)
  • Power
  • 3HP MOTOR Watt (w)
  • Dimension(L*W*H)
  • 40X25X48 Inch (in)
  • Color
  • BLUE
  • Warranty
  • YES
Product Description

APPLICATION

Thismachine is useful for Pharmaceuticals, Plastic, Bakelite, and Confectionery, Electronic Ferrite, catalysts (Flux), Ceramics, Air Fresheners and various other industries.

SPECIALFEATURES

Double side ejectors provided

TECHINICAL DATA OF

1.MAXIMUM DEPTH OF FILL- 32 MM

2.MAXIMUM SIZE OF TABLETS-50MM

3.DIAMETER OF DIE  -75MM

4. DEPTHOF DIE  -40MM

5.MAXIMUM STROKE - 35-40 STROKES (PER MIN)

6.PRESSURE TONS  -12  18 TONS

7.ELECTRIC MOTOR  -3 H.P / 440V / 50CYLS / 960 RPM (CROMPTON)

8.OVERALL DIMENSIONS  -770MM(L) X 560MM (B) X 640MM (H)

9. LUBRICATIONS -OILING AND GREASING NIPPLES

SPARKLER  FILTER PRESS

We manufacture Filter Press or Sparkler Filter form 8 " to 33 "

GMP MODEL MACHINE

Standard Specifications :

Sizes

:

8" j to 33 "j having 0.217 to 7.821m2 filtering area.

M.O.C

:

GMP model with SS-304/SS-316 wetted parts & non wetted of SS-304

Construction

:

SS-304/316 tank with Pressure tight lid, filter cartridge assembly having SS filter plates, support screen & interlocking cups.

Mounting

:

Complete unit is mounted on SS trolley.

Filter Media *

:

Polypropylene cloth.

Pump & Motor

:

SS304 / SS316 centrifugal pump with mechanical seal & 3j AC motor.

Standard Fittings

:

Inlet, outlet, pressure gauge, vent valve,  bypass valve & sampler (only for 14” and above sizes) All the valves shall have end connections flexible hose.

Gasket *

:

Silicon

Design Pressure

:

3 Kg/cm2
Hydrotest Pressure

:

4.5- 5 Kg/cm2
Finish

:

Buffing with mirror finish

* Specify the filter media & gasket M.O.C. in your P.O.

Technical Specifications :

Size of Filters

:

33
Shell Thick. (mm)



5
Top Cover Thick. (mm)

:

5
Height of Plate (mm)

:

38
Thick. Of Plate (Swg)

:

16
Pump Head(Mtr)

:

60
Pump Line Size

:

2
Dia. Perforated Screen (mm)

:

835
Thick. Of perforated Screen (mm)

:

1.6

Note : The flow rate mentioned is in terms of water with 5% carbon & filter media of poly

propylene cloth/paper & centrifugal pump. Filtration rate may change depending on

viscosity of liquids, quality of filter media and nature of solids in liquid to be filtered &

type of pump used.

PROVIDED AT VARIOUS POINTS

ALSO AVAILABLE WITH CENTRAL

LUBRICATION SYSTEM

ADDITIONAL COST.

Trade Information
  • FOB Port
  • Mumbai
  • Supply Ability
  • 1 Piece Per Month
  • Delivery Time
  • 8-10 WEEKS Week
  • Certifications
  • N.A
