LAB MODEL TABLET PRESS MACHINE

Next > >

<< Previous

Get a Price/Quote

Send Inquiry

Product Code : RDMTP

Brand Name : RIDDHI

Product Description

LAB MODEL TABLET PRESS

This lab model tablet press - riddhi mini press is built as per the GMP directives with total robust construction. At the same time, the necessary care has been taken to have trouble free operation, easy to clean and very low noise level. This state-of-the-art equipment can also be used for small batch production, thanks to its 'B' tooling specifications like 6 Tons pressure, maximum tablet diameter 16mm etc. which can be utilized for achieving the better output in its range. The maximum/minimum speed of the turret is achieved with the AC variable drive. Also the turret is equipped with key ways in upper guides as a standard feature. This small wonder is totally mobile and can be placed easily on table for laboratory use. As an additional precaution lower punch is equipped with seal (optional). A fixed feed frame ensures easy settings and lowest wastage of material.

Salient Features :

Easy Movability
Easy to Operate & Clean
Hard Heat Treated Rollers
AC drive with Fixed Pulley
Turret with key ways in Upper guides
Open fixed Feed Frame.
Drive from Center Pillar by worm reduction Gear Box
Built as per GMP directive
Fabricated Pressure Roller Carriers
Turret fitted Thrust Bearing
One piece Upper Cam Plate / Track

Technical Specifications :

Model	RDMP- 8D	RDMP- 10	RDMP- 8D	RDMP- 10B
No . Of Stations	8	10	8	10
Tooling	D	B	D	B
Max.Output (hr)	25,200	25,200	25,200	25,200
Max . Pressure	4 Tons	4 Tons	4 Tons	4 Tons
Pre-Compression	--	--	1 Ton	1Ton
Max . Tablet Dia.	23 mm	16 mm	23 mm	16 mm
Max . Dpt of Fill	20 mm	17.4 mm	20 mm	17.4 mm
Main Motor	2 H.P..	1.5 H.P.	2 H.P.	1.5 H.P.
