Double Cone Vacuum Dryer
Double Cone Vacuum Dryer operates under the principle of controlled and uniform drying under vacuum at low temperatures.
Uses
Is suited best for drying of free flowing non-sticky wet powder or crystals.
Advantages
Drying time much faster than that of conventional Tray Dryer Saves production time.
Uniform drying under controlled atmosphere at low temperature Good product quality free of oxides and dust with recovery of solvent.
Less manpower required Low drying cost.
Perfectly designed drive system - Saves power while drying.
Balanced movement - No foundation required.
Motorized Lump Breaker can be provided.
Design Aspects:
|
|
Total Volume | 50 to 10,000 Ltrs. |
Working Volume | 25 to 33 % |
Output Speed | 3 to 6 RPM |
Drive Motor | 0.5 HP to 5 HP |
MOC | IS 2062, ASTM SS 304, ASTM SS 316, PVDF coated |
Drying Time | 0.5 to 8 Hrs. |
Drying Temperature | 35 to 100 C and above |
Vacuum | Max. 760 mm. Hg |
Vacuum Breaking | By Air, N2 or any other Gas |
Heating Medium | Hot water / Steam / Hot oil |
Discharge | Provision of Butterfly Valve on requirement |
