Product Description

Pass-Through Oven

The Riddhi  Pass-Through Oven saves time when loading and reduces the danger of contamination, especially when directly transporting the chamber load between the grey room and the clean room.

The Riddhi  heating oven with fully insulated stainlesssteel door on both sides saves time during loading and

reduces the risk of contamination, specially when handling sensitive load between grey and clean rooms

Model                                          :     48 TRAYS  GMP MODEL

OVERALL SIZE Dimension                          :       2200(L) X 1200 (W) X 2150 (H)

TEMPERATURE                                            :       Up to 150C

INSIDE SHEETING                                   :      16 Guaqge Thick S. S. 304 Sheet Full welded.

OUTSIDE SHEETING                               :      14 Guage Thick S. S. 304

DOORS                                                         :       2 Doors Double Walled.

INSULATION                                              :     75 mm Thick Fibre Glass wool in all

.                                                                               Sides, top, bottom &door.

ELECTRICAL HEATER                             :       12KW ( Tubular Heater Type- 1 KW x 12 nos.)

BLOWER FAN                                            :       S.S.304

SHAFT                                                          :       S.S.304

NO.OFFANS                                              :       One BLOWER FAN

MOTOR                                                         :       3 Phase, 1440 RPM, 415 Volts

No.Of Motor                                                :       One MotorHP : 1 Hp 1400 RPM

CONTROL PANEL                                     :       TIC,Timer, Heater ON/OFF ,R Y B Indicator.

SENSOR                                                       :       PT. 100

AIR INLET FILTER                                 :       5 micron

AIR EXHAUST FILTER                             :       High temp 10 micron

FINISH                                                         :       Internal are buffed to 220 grit mirror finish.

     External are dull buffed matt finish
