VIBRO SIEVE
Single sturdy eccentric throw mechanism with standard motor.
Tubular frame for vibration free installation
Long scree travel provides fast, efficient method of size separation with adequate residence time to eliminate powder from the feed.
Quick clamp makes screen changing very fast.
Single as well as multi deck sieves for grading of different sizes of crumbs/pellets.
As the product travels and encounters the screening surface, the vibrating screen throws the product across the screen and separates the size required.
Low power requirement with high processing rate.
RD VS MODEL | 70X150 | 100X200 | 120X250 | 150X300 |
Sieve area (m2) | 1-2 | 2-4 | 3-6 | 4.5-9 |
MOTOR POWER KW | 1.1 | 1.5 | 2.2 | 3.75 |
Capacity (MT/Hr.) | 2-3 | 5-7 | 7-10 | 10-15 |
